YC-5000W wind turbine generator
|
model |
YC-5000W |
||
|
Rated power (w) |
5000W |
||
|
Rated voltage (VDC) |
DC400V/240V/200V | ||
|
Maximum power (w) |
5200W |
||
|
Start wind speed (m/s) |
2.5M/S |
||
|
work speed |
3~25M/S |
||
|
Rated wind speed (m/s) |
11M/S |
||
|
Maximum wind speed |
60M/S |
||
|
Wind turbine diameter (m) |
5.6M |
||
|
Number of leaves |
3 (Reinforced fiberglass) |
||
|
Controller mode |
Variable pitch control+automatic safety protection system (ASP) |
||
|
Maximum wind energy utilization coefficient |
0.40 |
||
|
noise |
Noise level: LP,25≤57.2DB | ||
|
Operating environment temperature |
-25℃~+50℃C |
||
|
Net weight |
400KG |
||
|
External dimensions |
Ф 5600MMX4000MM |
||
|
authentication |
CE /ROHS |
||
