Wind and solar co storage of new energy
YC-400W wind turbine generator
|
model |
YC-400/12 |
YC-400/24 |
YC-400/48 |
|
Rated power (w) |
400 |
||
|
Rated voltage (VDC) |
12 | 24 | 48 |
|
Maximum power (w) |
450 |
||
|
Start wind speed (m/s |
2.0 |
||
|
Cut in wind speed (m/s) |
2.5 |
||
|
Rated wind speed (m/s) |
12 |
||
|
Maximum wind speed (m/s) |
50 |
||
|
Wind turbine diameter (m) |
1.55 |
||
|
Number of leaves |
5 |
||
|
Ultimate disturbance of fan blades (mm) |
120 |
||
|
Noise (dB) |
<20 dB (based on 5m/s wind speed) |
||
|
Generator type |
Three phase permanent magnet direct drive |
||
|
Connection method between wind turbine and tower |
Flange connection or reducing head connection |
||
|
Whole machine weight (Kg) |
18 |
||
|
Environmental temperature (° C) |
-40~60 |
||
|
Strong wind protection |
Electromagnetic braking, blade stall, unloader |
||
